[促销] PV Industry Mete(9950A)

Model

CHT9950A

Display

95mm*20mm monochrome LCD

Test Parameters

leakage current/insulation IR

Voltage Resolution

1V

Voltage Accuracy

3%

Frequency

50Hz/60Hz

Output

AC

0.1kV-6kV

12mA

DC

0.1kV-6kV

6mA

Current Resolution

1uA

Current Accuracy

3%+2 counts

Voltage Ramp Up Time

0.1s-999.9s

Test Time

0.1s-999.9s

Arc Test Function

1~9 level

Insulation IR Range

100kΩ~100GΩ

Voltage Output

0.1kV~1.0kV

Memory Group

6 groups

Interface

PLC interface（Optional），RS232C （Optional）

Power Supply

Voltage：198V-240V AC Frequency：47Hz-63Hz

Pmax

100VA

Dimensions

value="374" tcsc="0" unitname="mm" w:st="on">374mm*280mm*99mm（L*W*H）

Weight

7.5kg
