5.1 标称容量/ Rated capacity 10Ah 0.2C rate discharge capacity
5.2 ***小容量/ Minimum capacity 10Ah
5.3 交流内阻/ Internal impedance ≤5mΩ
5.4 标称电压/ Nominal voltage 3.2V
5.5电芯重量/ Cell weight 0.33±0.05KG
5.6 标准放电方法Standard discharge conditions（1C） 恒流/ Constant current 5A
截止电压End-of-charge voltage 2.8V
5.7 标准充电方式Standard chargemethod 恒流/ Constant current 5A
充电电压Charge voltage 3.65V
5.8 快速充电方式Fast charge method 恒流/ Constant current 10A
充电电压Charge voltage 3.65V
5.9 ***大持续放电电流Max continuous discharge current 30A
5.10 脉冲放电电流Pulse discharge at 10 Sec 100A
5.11 循环寿命 Cycle life 1500 cycles 80% DOD
5.12 操作温度Operating temperature 充电温度Charging ambient temperature 0～45℃ Cell skin temperature should not exceed 70 .
放电温度Discharging ambient temperature -25～65℃ Cell skin temperature should not exceed 70℃
存储温度Storage temperature 0～45℃
5.13 外观/ Appearance 无破裂、划痕、变形、污迹、电解液泄露等Without break, scratch, distortion, contamination,leakage.
5.14 尺寸/Size L Length（长度) 70 mm
W Width（宽度） 27 mm
H Height（高度） 110 mm
