| 品牌： | YUANBO |
| 型号： | KN-SHSP010 |
| 太阳能板功率： | 10W/18V Wp |
| 蓄电池容量： | 12V/7AH Ah |
| Technical Data 技术参数 | |||||
| Item No. 产品型号 | KN-SHSP010 | ||||
| Solar Panel 太阳能板 | 10W/18V | ||||
| Battery Capacity 电池容量 | GEL 12V/7AH | ||||
| Controller 控制器 | 12V/5A | ||||
| lamp power 光源功率 | 2*3W LED | ||||
| 220V mains charger 市电充电器 | can charge battery on rainy days with grid power. 可在阴雨天用市电充电 (Input: 220V 50Hz ；Output:DC12V 1A） | ||||
| Inverter 逆变器 | none | ||||
| Output Interface 输出接口 | DC12V/DC5V | ||||
| PV cable length 太阳能板线长 | 5M | ||||
| LED lamp cable 光源线长 | 3M | ||||
| Packing material 包装材料 | Air inflation shockproof membrane inside+external carton box. 内置充气防震膜，外用纸箱 | ||||
| Packing information 包装信息 | Product size/weight: 254.5*129.8*195mm/5kgs; Packing size/weight: 360*280*130mm/6.3kgs. | ||||
| Application 应用 | can supply power to DC light,charge mobile phone, MP3,etc. 可带直流灯，给手机/MP3等直流电器充电 | ||||
| Name of load 负载名称 | Fully charged power 充满电系统可输出电量 | Power（W）功率 | Quantity 数量 | Working time(H) 工作小时 | Power consumption(WH) 耗电量 |
| Load reference -Single load 参考负载-单一负载 ( KN-SHSP010) | |||||
| LED lamp LED灯 | 63 | 2 | 2 | 15.7 | 63 |
| Mobile 手机 | 63 | 1.6 | 2 | 19.7 | 63 |
| Digital camera 数码相机 | 63 | 1.5 | 2 | 21 | 63 |
| Radio 收音机 | 63 | 2 | 2 | 15.7 | 63 |
| MP3 | 63 | 0.6 | 2 | 52.5 | 63 |
| Mini fan 迷你风扇 | 63 | 5 | 2 | 6.3 | 63 |
| Toy car 玩具车 | 63 | 1.8 | 2 | 17.5 | 63 |
