● 采用高导纯铝鳍片散热器,外观阳极氧化,让整体灯具重量更轻,体积更小, Adopt high purity Aluminum finned radiator ,the fin surface treatment of anodic oxidation,lighter weight ,smaller size.
● 采用原装进口美国科锐/飞利浦灯珠,高显色高光效,亮度可达130LM/W。 Adopt CREE /Philips LED chips imported from America,high CRI and high efficiency ,up to 130lm/W.
● 采用恒流恒压驱动,电源范围85-305VAC,各国电压均可使用 。Adopt Constant-current constant-voltage power supply ,operates in the 85~305 VAC range,widely use in every country.
● 采用进口磁悬浮电脑风扇,噪音小低于5分贝,寿命更长远。Adopt magnetic levitation Company fan,noise lower than 5 db,longer lasting .
● 采用防爆高聚光玻璃光学透镜,45度 60度 90度 120度多种照明角度可选,亮度可调.Adopt high concentrated explosion-proof optics lens,Brightness adjustable,multiple beam angle avalibale:45 °, 60°,90°,120°
●可定制调光(0-10/可控硅/DALI) 特殊照明(RGB/应急)Dimming(0-10V/Triac/Dali) and professional lighting(Emergency/RGB) customized available.
MAIN SPECIFICATIONS主要参数(t=20℃)
型号 Type | KW-SE100W | KW-SE120W | KW-SE150W | KW-SE200W | ||
功率 Power | 100W | 120W | 150W | 200W | ||
输入电压 Input voltage | AC85-305V 480-528V DC12/24/36/48V | |||||
电源频率 Freqency range | 50-60Hz | |||||
发光效率 luminous efficiency | 100-110lm/w | |||||
灯具效率 Lamp's efficiency | >90% | |||||
相关色温 Color temperature | 暖白 Warm white | 2700-3500K | ||||
正白 Pure white | 4000-5000K | |||||
冷白 Cold white | 6000-7000K | |||||
显色指数 Color rendering index | >80 | |||||
光束角 Beam angle | 120° | |||||
配光曲线 Light distribution | 圆形光斑Round spot | |||||
配光方式 Light design | LED+透镜LED+lens | |||||
LED 结点温升 Junction temperature | ≤30℃ | |||||
工作环境温度 Working temperature | -30℃——+55℃ | |||||
储藏环境温度 Storage temperature | -25℃——+65℃ | |||||
防护等级 IP Grade | IP65 | |||||
光源使用寿命 Working life-span | 50000H | |||||
灯头 base | E40、E39、E27、E26 | |||||
灯具 外壳颜色 Color of lamp shell | 黑色 Black | |||||
认证 Certificate | CE、ROSH、FCC、PSE |
适用:车间,仓库,大型收费站,加油站,超市,展览馆,商业大厦,停车场,矿山,工地,机库等;
Applications:workshops, warehouse, big toll station, gas station, supermarket, exhibition, commercial building, parking lot, mine lot, construction site, hangar;
